Classificador de cores

Classificador de cores
Télécharger

Classificador de cores:

Parâmetro técnico:

Name	RS256B/C-Z	RS320B/C-Z
Model	6SXZ-256B/C	6SXZ 320B/C
Channel	256	320
Capacity(t/h)	3~8	4~10
Sorting accuracy	≧99%	≧99%
Optimized carryover	>8：1	>8：1
Voltage(v)	AC220/50HZ	AC220/50HZ
Power(kw)	2.4	3
Air Pressure(MPa）	0.6-0.8	0.6-0.8
Air Consumption（m³/min)	<2.5	≦3
Weight(kg)	800	950
Size(mm)	185014601960	200014601960

Core Technology:
1.Global initiative hawkeye technology is adopted, deeply recognize tiny spot, light yellow and some other impurities that normal color sorter cannot recognize.

2.Global initiative hawkeye technology is adopted, deeply recognize tiny spot, light yellow and some other impurities that normal color sorter cannot recognize.

3. Global initiative yellow and chalky sorting technology can not only reject yellow and chalky grain together but also separate yellow and chalky grain in final rejection. Precise separation of yellow and chalky grain at the same time and ultra low carryover ratio truly realize the maximization of customer value.

4. Global initiative cloud internet of things system can provide real time online service, online technical support, online fault diagnosis, online data collection, online software upgrade, online data exchange and online operation management. Creating a new era of zero distance.

5. Global initiative cloud image high-speed capture and processing technology can recognize subtle differences that normal color sorter cannot identify and present perfect sorting result for customer.

6．Win Tone core cloud technology processing system with incomparable arithmetic capability realizes the overall improvement of capacity and sorting accuracy. Showing perfect sorting result and leading cloud era of sorting industry.

7. Intelligent high-frequency solenoid valve with high sorting accuracy, ultra-low air consumption and high switching frequency realizes optimized carryover ratio. It’s perfect self-recovery system ensures low maintenance cost and long lifetime over 10 billion times.

8. Adopting international advanced multi spectral analysis technology, hawkeye recognition technology and shape sorting technology can precisely recognize glass, plastic particles, dryers, gravel, etc. (optional)

9. The 360 degree stereo ring extraction system with super long dust cleaning interval improves processing efficiency.

VIDEO:
